Arfa 1018S - Page 34

CODE NO PART NO DESCRIPTION SPECIFICATION QTY NOTE
MODEL NO. 1018S
PARTS LIST
354-9
103127-3
Net Tube
1/2"x143cm 1
354-10
HD809
Net Tube
1/2"x32cm 1
355 198086J
Knob
2
355-1 198051AJ
Blade Tension Handle
1
356
CA51203
Bearing
51203 1
357
189053
Tension Indication Ring
1
358
198093
Spring Washer
∮ID16.3X∮31.5X1.8t 10
359
198026
Leadscrew
1
359
187067
Leadscrew
1
360
189050
Anchor Block
1
360-1
189041
Tension Scale
1
361
HS423
Hex. Headless Screw
M6-1.0Px15L 1
362
189051
Tension
1
363
HN008
Hex. Nut
M16XP2 1
364
121011
Washer
1
365
HS242
Hex. Head Screw
M8-1.25PX20L 1
366
189054
Screw
3
367
HW106
Spring Washer
∮10.2-3t 3
368
HS066
Hex. Head Screw
M10-1.5Px60L 3
369
189052
Press Board
2
370
HW105
Spring Washer
ø8.2-2.5t 4
371
HS240
Hex. Head Screw
M8-1.25Px10L 4
372 HF024
Hex. Head Screw
M6-1.0Px12L 2
373 W005
Washer
1/4"x16xt1.5 2
374 187022
Control Box
1
375 HS622
Flat Cross Head Screw
M6-1.0Px12L 2
376 187023
Control Plate
51
377 HE501
Cross Tablet Head Screw
M5-0.8Px8L 8
386 198170
Scale
1
603
193055
Presure Lump
1
604 HW007
Washer
∮12*t2 1
605 S013
Hex. Head Screw
3/8"*1-1/4"L 2
606 W013
Washer
3/8"*20*t2 2
608 193056
Presure Shaft
1
609 193059
Knob W/Shaft
1
610 290086
Plastic Round Knob
\RF31\ 1
611 CA51101
Bearing
1
612 HW007
Washer
∮12*t2 1
613 193058
Spring
1
614 187028
Acme Screw
1
-32-
