CH1 機型 Model Original
2
(1) 立銑、斜銑、鑽孔、搪孔、刻模、模具搪孔等作業均可於此垂直位置，當有必
要頭部可左右 45旋轉。
The turret milling machine is suitable for vertical milling, angular milling, drilling,
boring, diesinking, jig boring etc.. The vertical head may be tilted to 45from the
vertical position as necessary.
(2) 主軸轉速共有 8 段，從 80~2720rpm 能滿足不同材質和切削條件的需要。
The spindle speed ranges from 80 to 2720rpm. The model can fit the requirements
of various materials and working conditions.
(3) 主軸具有自動升降機構。
The quill is provided with 3 rates of feed, which can be used for both up feed and
down feed.
(4) 主軸經平衡校正具最佳之靈敏性。
Counter balanced quill and spindle provides extreme sensitivity.
(5) 具有昇降深度指示其精度達 0.0025mm (0.001”)。
Micrometer depth stop graduated in 0.025millimeters or 0.001 inches.
(6) 機體結構強靭，滑動面寬大，穩定性特佳。
The machine has a very strong construction and extra wide slidway offering
maximum rigidity and stability.
(7) 附有工作台自動進給裝置。
An accessory of table power feed unit.
本書重要性
Purposes of this manual
機器在使用前，操作者應對機器之構造、各種操作方法、保養、潤滑要有深入
的瞭解。本書即提供這方面的資料，請操作前詳讀本說明書，並遵照本書之說明，
做正確之操作與保養，使機器能保持高精密度及延長使用壽命，而得以發揮最大工
作效率。
We are gratefully to you for choosing our products, we are confident that our Milling
Machines will satisfy your expectations for they have many outstanding features such as
rigidity, high accuracy, versatility…etc. In order to manifest thoroughly the performances
of these Milling Machines, for it may be used for a long time without any trouble. We
expect all operators and those who concerned with maintenance will READ THIS
MANUAL CAREFULLY BEFORE STARTING THESE MACHINES for it describes
operation, inspection, maintenance, lubrication and procedures of set up of these Machines.
We hope all operators always consult this Manual, for these Machines long life.
