Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
83
ITIM
PARTS NO.
DESCRIPTION
1
5033
QUILL HOUSING ADJ.GEAR
2
5019
RAM ADAPTER
4
5027
NUT
6
5020
VERTICAL ADJUSTING WORM
7
5022
WORM THRUST WASHER (2 REQ.)
8
5021
VERTICAL ADJUSTING WORM SHAFT
9
5023
WORM KEY
10
5018
RAM
13
5035
SOCKET CAP SCREW (2 REQ.)
14
5034
ROLL DOWEL PIN
15
5043
ANGLE PLATE
16
5032
ROUND HD DRIVE SCREW (5 REQ.)
17
5026
ADAPTER PIVOD PIN
18
5029
CHAMFERED & HARDENDED WASHER (7 REQ.)
19
5028
ADAPTER LOCKING BOLT (3 REQ.)
23
2001
TABLE
31
2031
STOP PLECE T-BOLT (3 REQ.)
32
2030
TABLE STOP PIECE (2 REQ.)
33
2032
HEX NUT (3 REQ.)
37
3031
TABLE LOCK BOLT HANDLE
38
3030
SADDLE LOCK BOLT
39
3032
SADDLE LOCK PLUNGER
40
3036
SOCKET HD CAP SCREW (2 REQ.)
41
3028
GIB ADJUSTING SCREW (3 REQ.)
42
3035
TABLE STOP BRACKET
43
3026
SADDLE / TABLE GIB
44
3037
FELT WIPERS (4 REQ.)
46
3029
TABLE LOCK PLUNGER
47
3030
TABLE LOCK BOLT
48
3031
TABLE LOCK BOLT HANDLE
49
3027-2
SADDLE / KNEE GIB
49-R
KNEE BEVEL GIB – RIGHT
49-L
KNEE BEVEL GIB - LEFT
50
3037-2
SADDLE KNEE WIPER PLATE (4 REQ.)
51
3038
OVAL HEAD SCREW (8 REQ.)
52
3001
SADDLE
52-R
KNEE GUARD-RIGHT SIDE (FORWARD-BACKWARD)
