Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
88
ITIM
PARTS NO.
DESCRIPTION
56
4029
ALLEN CAP SCREW (2 REQ.)
57
4028-3
RIGHT HAND COLUMN WIPTER HOLDER
58
4028
KNEE WIPER FELT
60
3040
CHIP GUARDS – UPPER
61
3039
CHIP GUARDS – LOWER
62
4001
KNEE
64
1001-1
STIP SCREW
74
4023
JAM NUT
75
4020
KEY
76
4022
WASHER
77
4019
BEVEL GEAR
79
4040
SELED BALL BEARING
80
4039
BEARING RETAINER RING
81
4041
SOCKET HEAD CAP SCREW
82
4021
ELEVATING SCREW ASSEMBLY
83
4003
HANDLE
84
4002
ELEVATING CRANK
85
4013
GEARSHAFT CLUTCH INSERT
86
2016
DIAL LOCK NUT
87
4010
DIAL WITH 100 GRADUATIONS
88
4011
DIAL HOLDER
89
4009
SOCKET HEAD CAP SCREW
90
2011
BEARING RETAINING RING
91
2008
GREASE SEALED BEARING
92
4006
BEARING CAP
93
4015
KEY
94
4017
ELEVATING SHAFT FOR 12” KNEE
95
2008
GREASE SEALED BEARING
96
4014
BEVEL PINION
97
4042
SET SCREW
98
1001
COLUMN
99
4017-1
WASHER
102
4027
SOCKET HEAD CAP SCREW
103
4026
PEDESTAL
104
4024
ELEVATING SCREW NUT
105
4025
SOCKET HEAD CAP SCREW
118
5003
SPIDER
