Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
91
ITEM
PARTS NO.
DESCRIPTION
1
2004
JAM NUT (3 REQ.)
2
2018
BALL CRANK HANDER (3 REQ.)
3
2004
DIAL LOCK NUT (3 REQ.)
4
2012
DIAL WITH 200 GRADUATIONS (3 REQ.)
5
2014
DIAL HOLDER (3 REQ.)
6
2036
SOCKET CAP SCREW (6 REQ.)
7
2011
BEARING RETAINER RING (2 REQ.)
8
2008
GREASE SEALED BALL BEARING (2 REQ.)
9
2027
ROLL PIN (10 REQ.)
10
2026
SOCKET CAP SCREW (12 REQ.)
11
2006
LEFT BEARING BRACKET
12
2006
RIGHT BEARING BRACKET
13
2008
CREASE SEAL BALL BEARING
14
2003
KEY (3 REQ.)
15
2002
LONGITUDINAL FEED SCREW
MODEL:2S, 2VS 42” OR 49”
MODEL:3H, 3VH, 4S, 4VS, 5H, 5VH, 50” OR 54”
16
3021
SOCKET CAP SCREW (8 REQ.)
17
3019
CROSS FEED NUT RETAINING PLATE (2 REQ.)
18
3020
LONGITUDINAL FEED NUT
20
3041
KEY (2 REQ.)
21
3024
SOCKET CAP SCREW (8 REQ.)
22
3023
LONGITUDINAL FEED NUT BRACKET
23
3022
CROSS FEED NUT BRACKET
24
3020
CROSS FEED NUT
26
3005-1
STOP SCREW
27
3002
CROSS FEED SCREW
28
3005
CROSS FEED BEARING BRACKET

Argo 2S Specifications

General

Brand	Argo
Model	2S
Category	Power Tool
Language	English
