Argo 2S User Manual

CH10 零件圖 Spare Parts Drawing Original
93
ITEM
PARTS NO.
DESCRIPTION
L1
TABLE
L2
TABLE END COVER
L3
LEFT BEARING BRACKET
L4
RIGHT BEARING BRACKET
L5
LONGITUDINAL FEED NUT BRACKET
L6
LONGITUDINAL FEED NUT
L7
LONGITUDINAL FEED SCREW
L8
LONGITUDINAL FEED DRIVE HOUSING
L9
DRIVE HOUSING COVER
L10
RIGHT BEARING BRACKET RETAINER PLATE
L11
LONGITUDINAL FEED DRIVE SHAFT
L12
LONGITUDINAL FEED DRIVE GEAR
L13
DRIVE BEARING RETINER
L14
BEARING LOCK CAP
L15
DIAL HOLDER
L16
DIAL WITH 250” OR 200” GRADUATIONS
L17
DIAL LOCK NUT
L18
BALL CRANK
L19
HANDLE
L20
SADDLE
L21
SADDLE / TABLE GIB (L)
L22
SADDLE / TABLE GIB (R)
L23
SADDLE / TABLE ADJ. PLATE
L24
LEFT SADDLE HOLDING PLATE
L25
RIGHT SADDLE HOLDING PLATE
L26
SADDLE / KNEE GIB
L27
SADDLE / KNEE GIB
L28
TABLE LOCK BOLT
L29
TABLE LOCK PLUNGER
L30
SCREW (8×30mm)
L31
SCREW (10×25mm)
L32
ROLL PIN
L33
SCREW (6×20mm)
L34
SCREW (8×25mm)
L35
SCREW (6×30mm)
L36
SCREW (3/6”×3/8”)
L37
KEY (4×25mm)
