V 01/22
25
Do not use insecticides, oils, detergents or spray paints near
the appliance; do not use aggressive chemical detergents to
clean the casing: this may damage the finish and colour.
Close all open windows to maximise air conditioning efficiency.
The manufacturer will not be held liable if safety and accident
prevention rules are not observed.
DESCRIPTION OF THE APPLIANCE
FRONT VIEW
REAR VIEW
1) CONTROL PANEL AND FUNCTION BUTTONS
WITHOUT REMOTE CONTROL
2) FLAP, AIR INTAKE AND UPPER PANEL
3) FRONT PANEL
4) REAR PANEL
5) WHEELS
6) UPPER FILTER FRAME
7) HANDLE
8) REAR PART
9) AIR VENT
10) MIDDLE HOLE FOR CONTINUOUS DRAINGE
(ONLY IN DEHUMIDIFICATION MODE)
11) LOWER FILTER FRAME
12) LOWER DRAINAGE HOLE
13) POWER CORD
14) CABLE REEL
2
4
3
5
6
8
9
12
7
14
10
11
13
1
