Service Manual
9
Silk Screen on Display Board
PLATINIUM EVO 21 - PLATINUM EVO 41
● Top view
● Bottom view
NO.
1
Name
Interface of wire connec on between boards
for connec ng main board
Water level inspec on interface
Interface o emperature sensor and humidify
sensor
NO.
Name
4
Nixietube
2
5
Interface o ube temperature sensor
3
6
Interface of Stepping Motor
1
6
5
4
3
2
