Argo THOR PLUS - USE WITH WINDOW UNIT KIT

30V 12/23
(Fig. 1) (Fig. 2) (Fig. 3) (Fig. 4)
USE WITH WINDOW UNIT KIT
1. To make the hole in the glass, it is also advisable to take the porthole kit accessory to the glazier (Fig. 1).
2. Insert the porthole into the window (Fig. 2).
3. Insert the circular connector for the porthole kit into the retractable hose and insert the retractable hose with the
circular connector into the porthole without the cap (Fig. 3).
4. When not in use, disconnect the hose and close the porthole with the cap (Fig. 4).
Avoid tight bends or folds in the hose.
If the air conditioner is not used for prolonged periods, disconnect the pipe and plug the window unit.
