Argo THOR PLUS - APPLIANCE START UP; USE WITH END FITTING FOR WINDOW

29V 12/23
APPLIANCE START UP
Open the packaging and pull out the box. Remove the product and the other elements supplied (illustrated in the box
below).
Hose
of expulsion
of the air
Terminal flat fitting
to be placed between
window knockers
Porthole kit with cap
Condensate drainage pipe
to be used to empty the
internal tank
Battery for remote controller
type AAA – LR03 – 1,5 V r
Fitting to apply
on the unit to which
connect the exhaust pipe
of the air
Circular fitting for kit
porthole to be positioned between the
final part of the tube and the porthole
Remote
controller
USE WITH END FITTING FOR WINDOW
1. Stretch the exible hose sufciently so that it reaches the outside (max 1.5 m) and hook it to the rear part of the
air conditioner (Fig.1).
2. Open the window and lock one of the two leaves with the handle. Rest the terminal connection on the xed leaf,
bring the other leaf of the window close (Fig.2).
(Fig. 2)
(Fig. 1)
