Argon 18 E-119 - Remove Bicycle Handlebars; Pack Bicycle for Travel

7
Démontageetempaquetage
M6 x 16 mm
E-119TRI+DISC: travel guide
Removethehandlebar
1. Remove both M6 x 16mm screws from the first spacer.
2. Remove the first spacer.
3. Pack the first spacer and screws in the travel bag.
Packyourbike
1. Place and secure the handlebar on the non-drive side of the frame.
2. Pack the bike, wheels and small parts in the travel bag according to
bag instructions.
3. Make sure everything is secured (chain, handlebar, bridge assembly, etc.)
to avoid paint damage.
IMPORTANT:
Use a spacer in axles to avoid compression damage
during travel.
4
2.5
4
4
25
2 3
4
8
2.5
3
T25
T25
4
10
2.5
5
2.5
2.5
1.5
3
2.5
3
3
6
2.5
4Nm
8
3
1.5
HT
