NITROGEN : 3. Cable housing installation (continued)
Rear brake cable housing
Remove the 2 cable stopper (on the
head tube and near the seat collar).
Font section: Mesure the necessairy
cable housing to ensure a proper
rotation of the handlebar. Insert the
“KEB” cable housing and the cable
trough the top tube.
Rear section: With a magnet, get the
rear brake cable out of the frame, and
pass it trough the rear cable stopper.
Mesure the “KEB” rear housing correctly
to avoid interference with the rider’s
left leg.
KEB cable housing
4
5
