Arico TC5E - 2-2 Cabinet Specifications; 2-3 Connection Description

-10-
2-2 Specification
Type
T5A01
T5A02
T5A04
T5A06
T5A08
T5A12
Zone
Item
1
2
4
6
8
12
Power Switch
capacity(A)
--
32
50
50
63
63
Output
Connector
4pin+E
(ground)
16pins
x1
16pins
x1
24pins
x1
16pins
x2
24pins
x2
Power Cable
2.0mm
2
x3C
x3M
5.5mm
2
x5C
x3M
5.5mm
2
x5C
x3M
5.5mm
2
x5C
x3M
8.0mm
2
x5C
x3M
8.0mm
2
x5C
x3M
Weight(kg)
(non-module)
1.75
7.25
9
11.25
12.5
16
2-3 Connection description
Connector type
a: single hook b: single button
c: dual hook d: dual button
Connector
A
B
C
D
Name
Housing
Hood
Hood
Housing
T5E
T5F
T5F
T5E
Type
Socket
Plug
Socket
Plug
C o m b i n a t i o n
1*
a
b
b
A
2
c
d
d
C
3
d
c
c
d
*Standard type
**T5A01 only for type 1
