-2-
Chapter 1 TC5E TEMPERATURE
CONTROL MODULE
1-1 Features
■ Dual SV temperature control
■ Dual lines LED display
■ Unit display
■ Auto/Manual function
■ PID auto temperature control
■ Selectable two thermocouple types (J or K)
■ Selectable two temperature scales (°C or °F)
■ Selectable six alarm modes
■ Selectable two trigger output modes (Zero cross or phase angle)
■ Fuse break indicator
■ Power frequency auto-detect
■ Thermocouple break and inverse detect
■ Thermocouple range K T Y PE : 0 ~ 60 0 °C(32~999°F) / J T Y P E : 0 ~ 60 0 °C(32~ 9 99°F)
1-2 Specification
■ Power input: 230VAC±15%
■ Power frequency: 50 / 60Hz
■ Power consumption: 7W (each module)
■ Input impedance: 10MΩ
■ Output wattage: 3600W, 15A / 240VAC
■ Storage temperature: -20～70°C
■ Work temperature: 0～50°C
■ Work humidity: 10~80%RH. (non-condensing)
■ Control accuracy: ±0.25％FS
■ Measure accuracy: ±0.25％FS
