THE MANUAL
Before using the unit, carefully and completely
read your manuals. The contents will give you
an understanding of safety instructions and
controls during normal operation and
maintenance.
All reference to left, right, front, or rear are
given from the operator’s position, facing the
direction of forward travel.
SERVICE AND REPLACEMENT
PARTS
When ordering replacement parts or making
service inquiries, know the Model and Serial
numbers of your unit and engine.
Numbers are located on the product
registration form in the unit literature package.
They are also printed on a serial number label,
located on the frame of your unit (Figure 2).
• Record Unit Model and Serial numbers here
• Record Engine Model & Serial numbers here
PRODUCT REGISTRATION
A warranty registration card must be filled out
by the Ariens dealer, signed, and returned at
time of sale.This card activates the warranty.
Claims meeting requirements during limited
warranty period will be honored.
UNAUTHORIZED REPLACEMENT
PARTS
Use only Ariens replacement parts. Replacing
any part on this vehicle with anything other
than an Ariens authorized replacement part
may adversely affect the performance,
durability, or safety of this unit and may void
the warranty. Ariens disclaims liability for any
claims or damages, whether warranty,
property damage, personal injury or death
arising out of the use of unauthorized
replacement parts. To locate your nearest
Ariens Dealer, call 1-800-678-5443 or go to
www.ariens.com on the internet.
DEALER DELIVERY
Dealer should:
1. Check that all assembly and adjustments
have been properly completed.
2. Fill out Original Purchaser Registration
Card and return the card to Ariens.
3. Explain Ariens Limited Warranty Policy.
4. Explain recommended lubrication and
maintenance. Advise customer on
adjustments. Remind customer to
change oil in 4 cycle engine crankcase
after first two (2) hours of operation.
5. Instruct customer on controls and
operation of unit. Discuss and emphasize
the Safety Rules. Give customer
Owner/Operator, Parts, and Engine
manuals. Advise customer to thoroughly
read and understand them.
TABLE OF CONTENTS
INTRODUCTION
Serial Number
Label
Figure 2
OM1210
