GB - 12
CONTROLS AND FEATURES
See Figure 1 for locations.
Engine/Blade Control
The engine/blade control must be held against
the handlebar to start the engine and blade.
Releasing the control during operation stops
the engine and blade.
Handlebar
Adjust handlebar to a safe and comfortable
height. Refer to
Service and Adjustments
for
instructions.
Recoil Starter Handle
When pulled, handle will turn engine over.
OM0300
1. Speed Control Rod
2. Hair pin
3. Speed Control Bell Crank
1
2
3
Figure 5
OPERATION
WARNING:
Improper operation can
lead to injury. Learn what the
controls do and how they work.
Thoroughly read and understand
entire Operator Manual.
WARNING:
AVOID INJURY. Read
and understand
Operational, Fuel,
and
Battery Safety Rules
before
proceeding.
CAUTION:
Check function of
Engine/Blade Control regularly.
Improper function of control could
cause injury.
STOP START and RUN
OM1230
