Ariens 920013 - Specifications for Model 920013

GB - 35
SPECIFICATIONS
Model Number 920013
Description Compact 22
Engine Ariens OHV
Gross Torque* – lbf-ft (N•m) 9.5 (12.88)
*Engine output stated in gross torque per SAE J1940 as rated by engine manufacturer.
Displacement – in. (cc) 12.7 (208)
High Idle – RPM (min) 3600 ± 100
Electric Start 120V
Fuel Tank Capacity – qt (Liters) 2.7 (2.55)
Headlight Yes
Chute
Chute Rotation Angle 205°
Rotation Control 2.5X Quick Turn
Deflector Control Manual
Auger
Snow Clearing Width – in. (cm) 22.0 (55.8)
Gear Case Cast Iron
Auger Diameter – in. (cm) 11.0 (27.9)
Impeller
Impeller Diameter – in. (cm) 12.0 (30.5)
Impeller Speed (RPM) 1190
Impeller Tip Speed
– ft/sec (m/s) 3738 (1139)
Drive
Blower Drive HA Belt
Drive System
Disc-O-Matic
®
Speeds 6 Forward and 2 Reverse
Axle Control Pin-Lock
Pneumatic Tires – in. (cm) 13 x 4-6
Size and Weight
Length – in. (cm) 51.9 (131.8)
Height – in. (cm) 44.3 (112.5)
Width – in. (cm) 24.4 (62.0)
Weight – lbs (Kg) 172 (78)
