Step Four: Install Remote
Deflector Cable Cont.
6. Position rubber seal cap over the top of snap fitting.
7. Move deflector control lever to rear most position.
8. Attach cable eye to pin on bottom of deflector control lever.
NOTE: Hold down chute deflector cap, if needed, for more cable slack.
9. Secure cable eye to control lever with washer and hairpin.
10. Test controls to be sure deflector works properly. If deflector does
not follow full range of travel See Remote Discharge Deflector
Control Adjustment (920402, 403) of Owners Manual.
