ARIETE 1450 - Description of the Components

7
EN
DESCRIPTION OF THE COMPONENTS
A - Water tank lid M - Steam/hot water wand
B - Water tank N - Steam/hot water wand joint
C - Power cord O - Steam/hot water indicator light
D - Brewer P - Adjustable dispensing spout
E - Lateral door Q - Front display
F - Cleaning brush R - Upper display
G - Cleaning needle S - Power button
H - Water collection tray T - Dial for adjusting the grinding level
I - Drip tray U - Coffee beans container
J - Cup-holder grid V - Large coffee beans container
K - Coffee grounds container W - Coffee beans container lid
L - Steel tube
DESCRIPTION OF THE UPPER DISPLAY
(
R
)
WITH BUTTONS
Strong coffee button/indicator light.
Mild coffee button/indicator light.
Favourite beverage button/indicator light.
Steam button/indicator light.
Hot water button/indicator light.
DESCRIPTION OF THE FRONT DISPLAY
(
Q
)
WITH INDICATOR LIGHTS
Indicator light Status Meaning
Flashing
Insufficient amount of water.
The water tank is not installed.
On Lack of coffee beans in the container.
Steady The coffee grounds container is full.
Flashing
The drip tray is not inserted.
The coffee grounds container is not installed.
Steady The beverage is ready.
Flashing The beverage is being prepared.
