Ariston DB62 - Installation Diagrams

4
GB
Installation Diagrams
Ventilation slot here if cabinet
does not fit to ceiling.
Ventilation
slot here if
cabinet fits
to ceiling.
887mm
560mm
875mm
550mm
597mm
577mm
excluding
handle
Ventilation slot:
51mm x 457mm
min. area
560mm
Viewed down through
the cabinet.
Oven door
No. 6 x 15mm
screws
(4 supplied)
887mm
878mm if
trim is to
overlap
top edge
of shelf
*550mm
min.
*excluding
pipe work
and other
projections
560mm min.
574mm max.
50mm
Air gap
50mm
Air gap
Fig. 1
Fig. 2
Fig. 3
Fig. 4
