Electrical diagram
1. Detection Electrode
2. Ignition electrode
3. Gas valve
4. Water flow switch
5. Main P.C.B.
6. Control pannel
8. Outgoing water temperature sensor
9. Overheat thermostat water and fume
10. Ignition P.C.B.
1. galben/yellow
2. portocaliu/orange
3. maro/brown
4. roșu/red
5. roșu/red
6. negru/nero
9. portocaliu/orange
10. verde/green
13. alb/white
14. negru/black
15. portocaliu/orange
17. verde/green
18. portocaliu/orange
19. roșu/red
20. negru/black
Diagramă electrică
1. Electrod detecţie
2. Electrod aprindere
3. Robinet gaz
4. Comutator debit de apă
5. P.C.B. principal
6. Panou de control
8. Senzor de temperatură ieşire apă caldă
9. Termostat supraîncălzire apă şi gaze arse
10. P.C.B. aprindere
