Ariston FAST EVO - Dimensions; Minimum Clearences

12
noitpircsed tcudorp
Ø
A
k
m l
f
g
h
b
B
B
C
C
D
D
c
d
e
i
j
Model
Ø a b c d e f g h i j k l m
weight
gross net
11 l 113
580
37 87 228,5 310 54
58,8
131,5
210 230 25 16
22,5
9,6 8,9
14 l
132 70 117 264 370 48 230 250 23 11,2
11,0 10,2
16 l 1,112,215,131
Overall dimensions
B. Hot water outler 1/2”
C. Ingresso Gas 1/2”
D. Cold water inlet 1/2”
Minimum clearances
In order to allow easy access to the appliance for maintenance operations.
The appliance must be installed in accordance with the clearances stated below.
