product description
Technical Data
Model name : 61 41 11 FAST EVO ONT B
Type B
Gas category LPG
Maximum nominal heat input kW 21.5 27.0 31.0
Minimum nominal heat input kW 9.5 10.5 10.5
Maximum nominal heat output kW 19.0 24.0 27.5
Minimum nominal heat output kW 8.0 9.0 9.0
D.H.W. max temperature °C 65 65 65
D.H.W. min temperature °C 35 35 35
D.H.W. Nominal fl ow rate l/min 11 14 16
D.H.W. Minimum fl ow rate l/min >2 >3 >3
Water pressure maximum bar 10 10 10
Water pressure minimum bar >0.1 >0.1 >0.1
Required fl ow rate - combustion air m3/h 35.9 45.4 45.8
Flue fumes temperature at Minimum nominal heat input °C 190 190 190
MAX capacity fumes (G20) g/s 13.4 16.9 17.5
Minimum operating room temperature °C +5 +5 +5
Dimensions:
Height 580 580 580
Width 310 370 370
Depth 210 230 230
Electricity supply - Batteries 2x1.5V LR20
Ignition
by means of electric sparks
