Ariston FAST EVO User Manual

20
gninoissimmoc
Gas setting table
FAST EVO
ONT B 11
FAST EVO
ONT B 14
FAST EVO
ONT B 16
G20 G30 G31 G20 G30 G31 G20 G30 G31
lower Wobbe index (15°C, 1013 mbar)
MJ/m
3
45.67 80.58 70.69 45.67 80.58 70.69 45.67 80.58 70.69
Gas inlet pressure
mbar 20 28/30 37 20 28/30 37 20 28/30 37
Gas Burner Pressure- max mbar 15.0 24.3 32.3 14.0 26,4 34.7 11.1 21.21 28.5
Gas Burner Pressure- min mbar 3.0 4.5 6.7 2.2 3.5 5.0 1.4 2.42 3.0
Slow ignition pressur
mbar 4.0 5.5 8.3 2.71 4.1 6.0 1.9 2.7 3.6
Main Burner jets
nr. 11 13 14
Ø burner jets
mm 1.15 0.75 0.75 1.2 0.8 0.8 1.3 0.8 0.8
Max/min consumption (15°C, 1013 mbar)
(G.N.= m3/h) (GPL = Kg/h)
MAX 2.28 1.70 1.67 2.86 2.13 2.10 3.28 2.45 2.41

Ariston FAST EVO Specifications

General

Energy Efficiency	A
Voltage	220-240 V
Color	White
Dimensions	Varies by model
Weight	Varies by model
Installation	Wall mounted
Power	Varies by model
Frequency	50Hz
