ELECTRICAL SCHEME - BOX OF INTERNAL UNIT (FS 40 - 50)
BK = Black
BN = Brown
BU = Blue
RD = Red
OR = Orange
YE = Yellow
GN = Green
GY = Grey
WH = White
PI = Pink
WARNING:
BEFORE OBTAINING ACCESS TO TERMINALS, ALL
SUPPLY CIRCUITS MUST BE DISCONNECTED.
CONNECTION POWER MONOPHASE:
DO NOT REMOVE THE METAL PLATES FROM ITS SEAT.
CONNECTION POWER THREEPHASES:
REMOVE ONLY THE METAL PLATES INSERTED
BETWEEN THE PHASES L1, L2 AND L3.
