83 / GB
MENU
SUB-MENU
PARAMETER
DESCRIPTION
RANGE DEFAULT
0 NETWORK
0 2 BUS network
0 2 0 Network presence
System interface
Energy Manager
Heat Pump
Room Sensor
Zone Manager
0 3 System interface
0 3 0 Zone number
No zone selected
Zone selected
0
0 3 1 Room temperature correction - 3; +3 0
0 3 2 SW Version Interface
4 ZONE1 PARAMETERS
4 0 Setpoint
4 0 0 T Day 10 - 30 °C 19°C Heat - 24°C Cool
4 0 1 T Night 10 - 30 °C 13°C
4 0 2 T set Z1 par. 4.2.5 - 4.2.6 20°C (LT) - 40°C (HT)
4 0 3 Zone frost temperature 2 - 15 °C 5°C
4 1 Summer/Winter Changeover
4 1 0 S/W function activation Z1 OFF - ON OFF
4 1 1 S/W temperature threshold 10 - 30 °C 20°C
4 1 2 S/W delay time [0-600] 300 min
4 2 Z1 Settings
4 2 0 Zone 1 temperature range
Low Temp
High Temp
High Temp
4 2 1 Thermoregulation
Fix Flow T
Basic Thermoreg
Room T Only
Outdoor T Only
Room+Outdoor T
Basic Thermoreg
4 2 2 Slope 0,2 - 1 (LT); 1 - 3,5 (HT) 0,6 (LT) - 1,5 (HT)
4 2 3 Oset -14 ÷ +14 (HT); -7 ÷ +7 (LT) 0°C
4 2 4 Room Influence Proportional 0 - 20°C 2°C (LT) - 10°C (HT)
4 2 5 Max T 20°C ÷ 45°C (LT); 20°C ÷ 70°C (HT) 45°C (LT) - 60°C (HT)
4 2 6 Min T 20°C ÷ 45°C (LT); 20°C ÷ 70°C (HT) 20°C (LT) - 20°C (HT)
4 2 9 Heat request mode
Standard
RT Time Programs Exclusion
Forcing Heat Demand
Standard
4 3 Z1 Diagnostics
4 3 0 Room T only read
4 3 1 Room T setpoint only read
4 3 2 Flow temperature only read
4 3 3 Return temperature only read
4 3 4 Heat Request Z1 OFF - ON only read
4 3 5 Pump Status OFF - ON only read
4 4 Z1 Zone Module Settings
4 4 0 Zone pump modulation
Fixed
Modulating on DeltaT
Modulating on Pressure
Modulating on DeltaT
4 4 1 Target deltaT for pump modulation 4 ÷ 25°C 7°C (LT) - 20°C (HT)
4 4 2 Pump fixed speed 20 ÷ 100% 100%
4 5 Cooling
4 5 0 T Set Cool Z1 par. 4.5.6 - 4.5.7
7°C [FC] - 18°C [UFH]
4 5 1 Zone 1 Cooling Temp Range
Fan Coil
UFH
Fan Coil
4 5 2 Thermoregulation type
ON/OFF
Fix Flow T
Outdoor T Only
ON/OFF
4 5 3 Slope [18;33] FC; [0-30] UFH
25 FC; 10 UFH
