Ariston NIMBUS COMPACT M NET User Manual

84 / GB
MENU SUB-MENU PARAMETER DESCRIPTION RANGE DEFAULT
4 5 4 Oset [-2,5°C; +2,5°C]
0°C
4 5 6 Max T
MinT -12°C [FC];
MinT - 23°C [UFH]
12°C [FC];
23°C [UFH]
4 5 7 Min T 7°C-MaxT [FC]; 18-MaxT [UFH]
7°C [FC];
18°C [UFH
4 5 8 Target deltaT for pump modulation cooling [-5; -20°C]
-5°C
5 ZONE 2 PARAMETERS (IF PRESENT)
5 0 Setpoint
5 0 0 T Day 10 - 30 °C 19°C Heat - 24°C Cool
5 0 1 T Night 10 - 30 °C 13°C
5 0 2 T set Z2 par. 5.2.5 - 5.2.6 20 (LT) - 40 (HT)
5 0 3 Zone frost temperature 2 - 15 °C 5°C
5 1 Summer/Winter Changeover
5 1 0 S/W function activation Z1 OFF - ON OFF
5 1 1 S/W temperature threshold 10 - 30 °C 20°C
5 1 2 S/W delay time [0-600] 300 min
5 2 Z 2 Settings
5 2 0 Zone 2 temperature range
Low Temp
High Temp
Low Temp
5 2 1 Thermoregulation
Fix Flow T
Basic Thermoreg
Room T Only
Outdoor T Only
Room+Outdoor T
Basic Thermoreg
5 2 2 Slope 0,2°C - 1°C (LT); 1°C - 3,5°C (HT) 0,6°C (LT) - 1,5°C (HT)
5 2 3 Oset -14 ÷ +14 (HT); -7 ÷ +7 (LT) 0
5 2 4 Room Influence Proportional 0°C - 20°C 2°C (LT) - 10°C (HT)
5 2 5 Max T 20°C ÷ 45°C (LT); 20°C ÷ 70°C (HT) 45°C (LT) - 60°C (HT)
5 2 6 Min T 20°C ÷ 45°C (LT); 20°C ÷ 70°C (HT) 20°C (LT) - 20°C (HT)
5 2 9 Heat request mode
Standard
RT Time Programs Exclusion
Forcing Heat Demand
Standard
5 3 Diagnostic zone 2
5 3 0 Max Integral Action on Room Control only read
5 3 1 Z2 Diagnostics only read
5 3 2 Room T only read
5 3 3 Room T setpoint only read
5 3 4 Flow temperature OFF - ON only read
5 3 5 Pump Status OFF - ON only read
5 4 Z2 Zone Module Settings
5 4 0 Zone Pump Modulation
Fixed
Modulating on DeltaT
Modulating on Pressure
Modulating on DeltaT
5 4 1 Target deltaT for pump modulation 4°C ÷ 25°C 7°C (LT) - 20°C (HT)
5 4 2 Pump fixed speed 20 ÷ 100% 100%
5 5 Cooling
5 5 0 T set cool Z2 par. 5.5.6 - 5.5.7
7°C [FC] - 18°C [UFH]
5 5 1 Zone 1 Cooling Temp Range
Fan Coil
UFH
UFH
