Chapter 3: Configuration and commissioning
2X-A Series Installation Manual 49
Control panel configuration recommendations
Use the control panel configuration wizards to guide you through the
configuration process for most applications.
To access the configuration wizards press F1 (Wizards) from the installer level
Main menu.
In general we recommend the following configuration order:
1. Panel configuration (date and time, expansion boards, control panel ID and
description, fire network, and communications). For more information, see
“Panel configuration” on page 68.
2. Field configuration (loop devices, zones, and control panel inputs and
outputs). For more information, see “Field configuration” on page 98.
3. Change all default passwords for increased security. For more information,
see “Changing your password” on page 130.
Configuration controls
Use function buttons F1 to F4 and the jog dial (see Figure 3 on page 12) to
navigate the LCD menu, to select menu options, and to enter passwords and
system information, as shown below.
Entering passwords and
system in
formation
Turn the jog dial clockwise or anticlockwise to enter passwords
and other system information. Press the jog dial to confirm an
entry.
Selecting soft keys from the
LCD menu
Press the function buttons F1 to F4 to select the corresponding
menu options (Main menu, Logout, Exit, etc.).
Navigating and confirming
menu selections
Turn the jog dial clockwise or anticlockwise to select an option
from the on-screen menu. Press the jog dial to confirm the
selection.
The control panel ID on the LCD is white text with a dark background when the
jog dial is active (the control panel is waiting for input).
