Ariterm Biomatic+ 30 - Important Information

ARITERM SWEDEN AB Installation, Operation & Maintenance - 2009.02.18- 2/32
CONTENTS
Keep this instruction manual readily available for future use.•
Read the instructions carefully before taking your pellets installation into service.•
e capacity of the burner is calculated according to the maximum volume of •
pellets that can be fed to and burnt in the burn pot during 1 hour (based on a
normal, average wood pellets quality as described in our fuel specication)
Follow these instructions carefully and carry out care and maintenance work as •
recommended.
Notication to building authority
Attention! When you change heating installation this must always be
communicated to the local building authorities.
Sweeping
According to the re protection laws a chimney shall be swept regularly. is is done
by the local chimneysweep. Sweeping of the boiler shall be carried out in such a
manner that good operating economy is achieved. (see under ”Maintenance”) Prepare
to chimney-sweeping by turning o the boiler at least one hour before cleaning to
minimize the amount of glowing ash.
Warning! Make sure to cut the power supply to the boiler before removing the burner
housing.
Maintenance contract
Ariterm recommends the boiler installation to be made by a company with professio-
nal competence. For more information please contact your Ariterm retailer.
Replacing of spare parts
Ariterm recommends that replacing of spare parts is made by authorized serviceman
of Ariterm retailer. e retailer supplies required spare parts and authorized service-
man makes the necessary adjustments and combustion gas analysis when replacing
spare parts.
IMPORTANT INFORMATION
Important Information
.....................................................................2
Dimensions / Items included
/
Technical Data
........................ 3-4
Operating Principle
..........................................................................5
Safety and Alarms
.............................................................................6
Installation
.........................................................................................7
Water Piping
.....................................................................................7
VVS Installation ...........................................................................8-9
Filling of Water
.................................................................................9
Wiring Diagram
..............................................................................10
Control Panel
..................................................................................11
Control Computer and Menus ......................................................11
Settings ............................................................................................12
Burner Overview
.............................................................................12
Start-up in OFF Mode
...................................................................13
Start-up in Operating Mode
.........................................................13
Displayed Messages
..................................................................14-15
Actions Chart +20 .........................................................................16
Actions Chart +30 .........................................................................17
Troubleshooting
........................................................................18-19
Maintenance, Care, Sweeping
..................................................20-21
Advice about Fuel Pellets
...............................................................22
Guarantee
........................................................................................22
Storage Planning
.............................................................................22
Feeding System .........................................................................23-26
Manufactures Declaration .............................................................27
Notes .........................................................................................28-30
Installation Protocol.... ...................................................................31
