Ariterm Biomatic+ 30 - Installation Protocol; Burner Adjustment and Performance Testing

ARITERM SWEDEN AB Installation, Operation & Maintenance - 2009.02.18- 31/32
After installation the burner has to be adjusted. To test every power range, press plus key for 8 seconds in On/O menu, then can high, low and min modes be tested
manually. Returning to normal position: Press minus key once.
ATTENTION! In this function, the burner won’t stop when the boiler water reaches desired temperature: boiling risk!
If these instructions are not followed during installation, operation and maintenance,
the obligations of Ariterm AB under the warranty regulations are no longer binding.
Ariterm reserves the right to alter any details and specications without prior notice.
INSTALLATION PROTOCOL
Flue gas temp. High CO O
2
CO
2
Air-fuel ratio
Efciency Draught i mm
Fan
Effect %
Flue gas temp. Low CO O
2
CO
2
Air-fuel ratio
Efciency Draught i mm
Fan
Effect %
Flue gas temp. Min
CO
O
2
CO
2
Air-fuel ratio
Efciency Draught i mm
Fan
Effect %
Retailer / Installer
Installed by
Inst. date
