Ariterm Biomatic+ 30 - VVS Installation

ARITERM SWEDEN AB Installation, Operation & Maintenance - 2009.02.18- 8/32
BIOMATIC+ 20 or 301.
Shunt valve, oor heating (radiator heating)2.
Extra shunt connection, radiator heating (oor heating)3.
Circulation pump, oor heating4.
Circulation pump, radiator heating5.
Floor heating distributor with choke valve and draught check plate6.
Radiator heating circuit7.
Expansion vessel8.
Service valve9.
Safety valve10.
Filler valve11.
Valve pipe with safety valve12.
Circulation pump for drain water13.
Expansion card14.
Outdoor temperature sensor15.
Flow water sensor16.
WATER PIPING
6
4
1
8
9
10
11
13
15
16
16
12
2
3
5
7
14
