Menu Setting Description
Drop Off, 1-5, 1-7, 6-7
Days when drops are to be carried out. 1-5 = Mon-Fri, 1-7
= Mon-Sun and 6-7 = Sat-Sun
Start 00.00 - 24.00 Time at which the drop starts
End 00.00 - 24.00 Time at which the drop ends
Drop 2 Off, 1-5, 1-7, 6-7
Days when drops are to be carried out. 1-5 = Mon-Fri, 1-7
= Mon-Sun and 6-7 = Sat-Sun
Start 00.00 - 24.00 Time at which the drop starts
End 00.00 - 24.00 Time at which the drop ends
Temperature 0-30°C Temperature of the drop
Time 0-23 h and 0-59 min Time determination
Drop menu
Menu Setting Description
Fine adjustment -40 - +20 °C Parallel transfer of the temperature graph
Graph 23-56 °C Temperature graph determination (outdoor temperature 0 ºC)
Supply water min 10-50 °C Supply water minimum temperature
Supply water max 30-80 °C Supply water maximum temperature
Heat Regulation 2 menu
e Drop menu can be used to determine the two times when the supply water temperature
is decreased by a set value. Set first the right time so that the drops are carried out at the right
time. For example, the setting 1-5 means the time between Monday and Friday.
HEAT REGULATION MENU STRUCTURE HEAT REGULATION EXAMPLES
e following section contains examples of the different heating systems and their settings. e
settings are indicative and fine adjustment might be required.
Floor heating system
A thermostat is installed in the circulation pump control of the heating circuit. e thermostat
switches the pump control off if the supply water temperature rises above 45 ºC. If the supply
water temperature is too high, this may damage parquet floor.
If, when the outdoor temperature is below 0 ºC, the room temperature is too low, slightly in-
crease the Graph setting. Correspondingly, if the room temperature is too high, decrease the
setting. In summer, the Supply Water Min setting can be used to ensure a comfortable floor
temperature.
If the room temperature feels too high or too low while the outdoor temperature is between -5
ºC and +5 ºC, the shape of the graph can be modified through the Compensated Graph set-
tings. e settings can be used to increase/decrease the supply water temperature.
If an indoor temperature sensor has been installed, the sensor automatically corrects the sup-
ply water temperature to obtain the desired indoor temperature. e room coefficient is used
to determine how many degrees the supply water temperature must decrease in order for the
room temperature to increase by 1 ºC.
Menu Floor heating system
Radiator heating sys-
tem
(well-insulated building)
Radiator heating sys-
tem
(normally insulated buil-
ding)
Graph 28 °C 40 °C 50 °C
Supply water min 20 °C 17 °C 17 °C
Supply water max 40 °C 70 °C 80 °C
Compensated graph +5 °C = 0 °C +5 °C = 0 °C +5 °C = 0 °C
Compensated graph 0 °C = 0 °C 0 °C = 0 °C 0 °C = 0 °C
Compensated graph -5 °C = 0 °C 5 °C = 0 °C 5 °C = 0 °C
Room coefficient 2 °C 4 °C 4 °C
Circulation pump stop 20 °C 20 °C 20 °C
