Arjo Opera - Patient Scale and Supplementary Instructions; Patient Scale Usage Reference

28
When the patient is returned and lowered on to the
bed, the strap stretcher may be removed, once
disconnected from the stretcher frame, by
slackening all the clamps on one side section and
gently pulling each strap through under the patient.
Disconnect and remove the frame, store carefully
for future use.
Patient Scale (if fitted)
See seperate supplementary operating instructions.
Fig. 50
mP1389a, P1396d, P1265
Strap and scoop stretcher
connection hook positions
label - hook positions for strap and
scoop stretcher attachment straps
•Note: Individual patient support
straps can be slackened and removed if
access is required to any part of the
patient needing attention.
Warning: Do not remove too many
straps at one time to ensure the patient is
securely supported.
Using your Opera
