35
Component Weights
kg lbs
Opera (mast with ‘Lock and Load’ jib) - less battery ................. ..........36.9 (81.3)
Opera (mast with ‘Lock and Load’ scale jib) - less battery ........ ..........40.1 (88.4)
Opera (mast with P.P.P. jib with 4 point spreader bar) - less battery ......46.4 (102.3)
Opera (mast with P.P.P. scale jib with 4 point
spreader bar) - less battery ........................................................... ..........49.6 (109.3)
‘V’ opening chassis...................................................................... ..........21.1 (46.5)
4 point spreader bar ‘Lock and Load’ system .............................. ..........6.0 (13.2)
2 point spreader bar ‘Lock and Load’ system .............................. ..........2.1 (4.6)
Stretcher frame............................................................................. ..........7.0 (15.4)
Scoop stretcher............................................................................. ..........9.7 (21.3)
Strap stretcher............................................................................... ..........13.6 (29.9)
Battery pack.................................................................................. ..........4.9 (10.8)
Electrical
Battery type and part number ...................................................... (Rechargable - lead acid) KPA0100
Battery capacity ........................................................................... 5Ah
Battery charger part number ........................................................ KPA0101**
(Note: ** indicates relevant country code)
Handset - Protection class ........................................................... IP67
Lifter nominal voltage ................................................................. 24V DC
Medical Equipment:- type protection against electrical shock in accordance with IEC 601-1)
ARJO patient handling products meet the requirements of Electromagnetic Compatibility (EMC) as stated in
clause 12.5 of the Medical Devices Directive 93/42/EEC
Duty cycle Max volts Max amps
Mast Lift Actuator ....................................................................... 15% (9 min/hr) 24 8
‘V’ Chassis Actuator ................................................................... 10% (6 min/hr) 24 4.5
Scale
Power supply................................................................................ 6 Volt DC (4 x AA Batteries)
Battery life.................................................................................... 120hrs
Accuracy....................................................................................... 2-120kg (4-265lbs) ± 100g (0.2lb)
Accuracy....................................................................................... 4-200kg (10-440lbs) ± 200g (0.5lb)
Protection class............................................................................. IP 53
Environment
Air humidity/storage .................................................................... 80% @ 20°C (68°f)
Usage temperature range (ambient) .............................................. +5°C (41°F) to +35°C (95°F)
Optimum usage temperature (ambient)......................................... +20°C (68°F) to +25°C (77°F)
Storage and transportation temperature (ambient) .................................. -10ºC (14ºF) to +45ºC (113ºF)
Technical Specification
