KM-10 User Manual V1.10
3. Technical Specifications
Input supply:
Supply voltage:
20VAC±10%
Max. Power consumption:
10W (Control circuit) + Motor power
Supply protection:
Short-circuit protection (8A)
Motor outputs:
Motor voltage:
24VDC
Motor output power:
Max. 200W (8A)
Motor control type:
4-region motor control
Motor protection:
Motor output overload and short-circuiting protection
Encoder inputs:
Encoder type:
Incremental (2-channel incremental encoder)
Note: Encoder is not included
Encoder resolution:
Any model between 100 pulse and 2048 pulse
Encoder voltage:
5VDC
Output signals:
Outputs for control panels:
Door open signal
Door closed signal
Door obstruction or photocell detected signal
Output type:
With relay contact output
3A @ 250V AC or 30V DC
Input signals:
Door control & speed signals:
(Opto-coupled)
Open signal
Close signal
Other inputs:
Photocell & obstruction signal
NDG signal to activate nudging mode
Input type:
Activated with 24VDC
Battery connection:
Battery voltage:
2 pieces 12V/1.2Ah batteries
Internal battery charge:
Not Included
Battery protection:
With fuse
User interface:
Standard interface:
2x16 Character display and 4 keys
Warning sound:
With buzzer
Language options:
Turkish, English, Greek
Mechanical features:
Dimensions:
116 x 160 x 50 mm (Width x Length x Height)
Working capability:
Door opening:
50 cm – 300 cm
Motor power
Max. 200W
Door opening-closing velocity:
20 cm/s – 50 cm/s
Door opening-closing slow
velocity
2cm/s – 19 cm/s
