Electromagnetic Flowmeter M-910
50
Operation manual
DN (mm) PN (bar) D (mm) A (mm) L (mm) Weight (kg)
10 16 90 140 150 3
15 16 95 145 200 3
20 16 105 150 200 3,5
25 16 115 155 200 3,5
32 16 140 165 200 5
40 16 150 175 200 6
50 16 165 185 200 7
65 16 185 200 200 9
80 16 200 215 200 11
100 16 220 235 200 12
125 16 250 265 300 22
150 16 285 295 300 24
200 16 340 355 400 35
250 10 395 435 400 42
300 10 445 485 500 56
350 10 505 535 500 70
400 10 565 580 500 95
500 10 670 695 500 120
600 10 780 800 600 160
700 10 895 900 700 230
800 10 1015 1010 800 330
Table 1: M910 dimensions and weights – DIN flanges
9.2 Used materials
Electromagnetic flowmeter is made from materials, which meet international standards and conventions.
Liner:
Hard rubber as standard
Teflon - PTFE
Electrodes CrNi (stainless) steel 1.4571 as standard
Hastelloy C276
Tantalum
Sensor tube Stainless steel 1.4201, dimensions according to DIN 17457
Flange Steel 1.0402 or higher, dimensions according to DIN 2501 (BS 4504), ANSI
B16.5
