Electromagnetic Flowmeter M-910
60
Operation manual
FLOWMETER submenu structure
2.A
Datalogger
Sampling rate in
minutes,
datalogger clear
(OFF, 5, 10, 15, 30, 45,
60, 120, 180, 240, CLR)
2.9
Date setting
Real time clock
date setting
2.8
Time setting
Real time clock
time setting
2.7
Time constant
Time for flowrate
moving average
1...20 sec
2.6
Low-flow cutoff
Flowrate for Low-
flow cutoff
Positive 2.5
Flowrate
direction
Negative
0
0.0
0.00
0.000
2.4
Volume
resolution
0.0000
m3 (cubic meter)
l (liter)
US.G (US gallon)
2.3
Volume units
user (user defined units)
0
0.0
0.00
0.000
2.2
Flowrate
resolution
0.0000
l/s (liters per second)
m3/h (cubic meters per hour)
G/m (US gallons per minute)
Key UP
2 FLOWMETER
2.1
Flowrate units
User (user defined units)
Key ENTER
Key ESC
GENERAL submenu structure
3.7
Password menu
Password changing
On 3.6
Current loop test
Off
On 3.5
Self test
Off
3.4
Power supply
Information only (Power supply voltage and
frequency).
3.3
Serial number
Flowmeter serial number.
3.2
Nominal range
Flowrate for Q
N
.
Key UP
3 GENERAL
3.1
Diameter
Diameter in mm.
Key ENTER
Key ESC
