Armitage Shanks Sensorflow 21 compact A4854AA - Table of Contents

2
TABLE OF CONTENT
1 IMPORTANT PRE-INSTALLATION NOTES ................................... 3
2 PRODUCT BOX CONTENTS ......................................................... 4
3 SUPPLY CONDITIONS .................................................................... 5
3.1 WATER REGULATIONS ..................................................................................... 5
4 URINAL PLUMBING ARRANGEMENTS ........................................ 6
5 INSTALLATION GUIDE .................................................................... 8
5.1 MOUNTING SENSORS ...................................................................................... 8
5.2 PLUMBING OVERVIEW ................................................................................... 10
5.3 ELECTRICAL CONNECTION ..........................................................................13
6 URINAL OPERATION .................................................................... 18
7 SENSOR RANGING & RUN TIME ADJUSTMENT ..................... 19
8 EXTENSION CABLES ................................................................... 20
9 MAINTENANCE ..............................................................................20
9.1 SOLENOID VALVE ............................................................................................20
9.2 HYGIENE FLUSH (AUTOMATIC) ....................................................................21
10 CLEANING CHROME SURFACES ............................................... 22
11 SPARE PARTS ............................................................................... 23
Sensorow 21 compact urinal ushing devices
(surface & panel mount versions)
These compact panel & surface mount (PM & SM) Sensorow 21 electronic urinal ushing products are
designed for water economy & hygienic “no-touch” operation.
The urinal ush is operated by the infrared sensor which detects the presence of the user in the sensing
region. When the user moves away, the ush is triggered automatically. Water will ow for the preset
run-time.
These products are intended to be supplied with cold water.
The two designs, PM & SM are each available in 3 versions: Mains powered (transformed) with option
to link up to 5 link units & independent battery powered units:
A4670AA (PM) & A4671AA (SM) are supplied with battery unit
A4854AA (PM) & A4856AA (SM) are supplied with mains power unit
A4855AA (PM) & A4857AA (SM) are supplied with link unit
(Link up to 5 per A4854AA or A4856AA)
