1.0 MANUAL INTRODUCTION
1.1 PREFACE
This manual contains important information for
reliable proper and efficient operation. Compliance
with the operating instructions is of vital importance
to ensure reliability and a long service life of the
product and to avoid any risks.
The first chapters contain information about this
manual and safety in general. The following chapters
provide information about normal use, installation,
maintenance and repairs of the product. The anexes
contain the technical data, the parts drawings and
the declaration(s) of conformity.
Make yourself familiar with the content.
Accurately follow the directions and
instructions.
Never change the sequence of the operations
to be carried out.
Keep this manual or a copy of it together with
the logbook in a fixed place near the product
which can be accessed by all personnel.
1.2 ICONS AND SYMBOLS
In this manual and in all accompanying documenta-
tion the following icons and symbols are used.
WARNING
Danger of electric Voltage. Safety sign accord-
ing to IEC 417 - 5036
WARNING
Operations or procedures, if carried out without
caution, may cause personal injury or dam
age to the product. General haz ard sign ac
cording to ISO 7000-0434
ATTENTION
Is used to introduce safety instructions whose
non-observance may lead to damage to the
product and its functions.
ENVIRONMENTAL INSTRUCTION
Remarks with respect to the
environment.
2.0 IDENTIFICATION, SERVICE AND
TECHNICAL SUPPORT
2.1 OBTAINING DATA AND INFORMATION VMS
02A, 04A, 06A, 10A, 15A, 85A
The name plate indicates the type series / size, main
operating data and identification number. Please
quote this information in all queries, repeat orders
and particularly when ordering spare parts. If you
need any additional information or instructions
exceeding the scope of this manual or in case of
damage please contact Armstrong's nearest customer
service centre.
Figure 1: Pump with motor
Figure 2: Pump without motor
Figure 3: Duty point
