2.3 SEAL CODES
Table 3: Material code shaft seal
2.4 CURRENT
2.4.1 NOMINAL CURRENT
VMS 02A, 04A, 06A, 10A, 15A, 85A
The nominal allowable current of the motor is stated
on the motor plate. This shows the nominal working
range of the motor and can be used to protect the
motor.
Measuring the actual current of the pump during
operation can be used to pre-set the motor protection
switch to protect the pump/motor combination.
This current value can also be used to determine the
proper electrical equipment such as variable
frequency drive, main switch, wiring diameter etc.
WARNING
Not only the motor, but also the pump has
to be protected in its application.
2.4.2 MAXIMUM CURRENT
VMS 32A, 45A, 65A
The maximum allowable current of the motor is men-
tioned as I.max. on the motor plate. This maximum
allowable current shows the maximum working range
of the motor and can be used to protect the motor.
WARNING
Be careful in using it this way, because, not
only the motor, but also the pump has to be
protected in its application.
On the pump plate (sleeve sticker) this "pump current
at 400 Volts" will be mentioned as I nom. and can be
used to pre-set the motor protection switch to protect
the pump/motor combination.
Code acc. to EN 12756 Description Material Note
B Spring loaded ring Carbon graphite Ca Resin impregnated
Q1 Silicon carbide SiC Sintered pressureless
U3 Tungsten carbide TuC CrNiMo-binder
A Seat ring Carbon graphite Ca Antimony impregnated
B Carbon graphite Ca Resin impregnated
Q1 Silicon carbide SiC Sintered pressureless
U3 Tungsten carbide TuC CrNiMo-binder
E Elastomers EPDM EPDM Ethylene propylene rubber
V Viton Viton Fluor carbon rubber
X4 HNBR HNBR Hydrogenated nitrile rubber
G Spring CrNiMo steel
G Other metal parts CrNiMo steel
This current value can also be used to determine the
proper electrical equipment such as variable fre-
quency drive, main switch, wiring diameter etc.
2.5 SUPPLEMENTARY DOCUMENTATION
Apart from this manual, the documentation given
below is also available:
Q:
H:
Ser.Nr:
I nom:
P:
n:
duijvelaar pompen
Armstrong pumps
Document Date/ Code
General terms of delivery 10-1998 119 / 1998
Technical Data 50Hz
version B
02-2010 97004455
Technical Data 60Hz
version B
02-2010 97004435
VMS 32A, 45A & 65A
Engineering Reference 11-2008 BE00000329
Technical Data 50Hz 07-2008 97004434
Technical Data 60Hz 07-2008 97004435
Technical Data 60Hz 12-2007 97004436
Motec operating instruc-
tions
09-2001
BA-8200-
motec-
frequency-
inverters-V3-
See also armstrongintegrated.com
VMS 02A, 04A, 06A, 10A, 15A & 85A
