SC-350/SC-360 – User’s Guide – 019223-101 Rev 06
6
Machine Part Terminology
10
11
SC-350
SC-360
7
13
4
3
2
8
5
6
1b
1a
12
9
1a Coin tray SC-360
b Coin tray SC-350
2Control panel
3Diameter selector
4Coin outlet
5Inspection cover
6On/Off switch
7Thickness selector
8Reject cup
9Fuse
10 RD/AUX connection
11 Serial interface connection
12 Power cord/Mains Inlet
13 Coin diverter
Caution!
Do not use as a lifting handle.
