2. Status Indicators
Arriflex 435 Quick Guide, 9/97, Page 6
Viewfinder indicators: Red LED Asynchronous operation; camera is not running at set fps rate
ASY: Asynchronous operation; camera is not running at set fps rate
END: Camera ran out of film
BAT: Battery too low for the set fps rate
≤130 fps: less than 20.6 V; 130 - 150 fps: less than 24.1 V
Display indicators:
■■ glows The display is in mode 1
bat glows Battery too low for the set fps rate
≤130 fps: less than 20.6 V; 130 - 150 fps: less than 24.1 V
bat blinks Battery is too ”soft”, voltage will collapse on use
asy glows Asynchronous operation; camera is not running at set fps rate
asy blinks Movement and shutter are not synchronous
end glows Camera ran out of film
fps blinks Wrong magazine for currently set fps rate
or, if connected, ESU is not getting a valid signal
PROG glows Internal program is activated
PROG blinks Internal program cannot be run: out-of-range fps or shutter
values, wrong magazine for programmed fps values, or
battery too low for programmed fps values
R glows Camera is set to run in reverse
TC glows Timecode exposure is enabled and timecode is set
TC blinks Timecode exposure is enabled, but not recording properly
OFF Lower line: SEL/SET button is pressed & locking slider is locked
OFF Upper line in mode 7: electronic shutter of 435ES is off
Shutter blinks See below
Shutter blinks (435ES):
Shutter blinks: The electronic shutter adjustment feature of the 435ES has been turned off.
Shutter blinks & red LED: If shutter is locked, it should be unlocked.
Shutter blinks & red LED: If shutter is unlocked, the electronic adjustment feature is defective. Turn
electronic adjustment off and set the shutter manually to continue filming.
Display warnings: The LCD Display will indicate any situations that will prevent running the
camera by changing one or more of its digits into underlines.
