Monitoring 71
Activation of Return In
Return In can only be switched on and off using a user button assigned with Return In.
► Select MENU > User Buttons and assign Return In to the desired button.
► Press the user button to activate Return In.
14.10 SDI Color Bars
The camera supports to output SMPTE color bars on the SDI outputs. The color bars are a 10-bit signal
according to SMPTE RP 219-2002. Color bars will always bypass the ALF4 look file. These are SDR
color bars, set the SDI color space to either Rec 709 (SDR) or Rec 2020 (SDR) for correct display.
► Select MENU > Monitoring > SDI Color Bars to switch color bars on or off.
Info: Color bars are switched off when recording is started.
User Button SDI Color Bars supports to quickly enable/disable color bars on the SDI outputs.
