ARRI ALEXA Plus - Page 317

*XT = function available on ALEXA XT/XR only *ANAMORPH = requires Anamorphic Desqueeze License *DNxHD = requires DNxHD License *HS = requires
High Speed License *PLUS = ALEXA PLUS only *PLUS 4:3 = ALEXA PLUS 4:3 only *STUDIO = ALEXA STUDIO only *M = ALEXA M only *NON XT = only
available on ALEXA „Classic“ cameras *OG = settings and values introduced by the Open Gate Mode are not covered by this overview.
SUP 9.0
continued on next page
WRS*
ALEXA (XT) PLUS/PLUS 4:3 & STUDIO
RADIO
STATUS
Channel: 0
Units: 0
Ready/Off
WRS > RADIO >>
WRS radio power (On/Off)
WRS radio channel (0-7)
LENS DATA
LDS READOUT
Status
LENS DATA
displays FOCAL LENGTH, IRIS,
FOCUS and DoF close/far
LDS OPTIONS
Lens distance unit (Metric, Imperial, Default Unit)
Circle of confusion (0.013/0.025/0.035/0.050mm)
Inverse iris scale (On/Off)
Inverse zoom scale (On/Off)
Inverse focus scale (On/Off)
LDA available when non-LDS lens in use
manage lens data for non-LDS lenses
CAM LEVEL
STATUS READOUT FROM SENSORS
Tilt: 0.0°
Roll: 0.0°
CAM LEVEL > RESET
use to reset your null balance
IRIS/ZOOM/FOCUS CLM
CLM STATUS
displays TYPE, DIRECTION and TORQUE(1-4; CLM-3 & 4)
IRIS/ZOOM/FOCUS CLM
set DIRECTION
set TORQUE (only for CLM-3 & 4)
CALIBRATE/CALIBRATE ALL motors
ELECTRONIC VIEWFINDER EVF-1
magnify EVF image 2.25x (toggle mode)
false color exposure check (toggle mode)
ZOOM
EXP
Options may differ
depending on the lens
you‘re using (LDS/Non-LDS)
On ALEXA (XT) M
via SYSTEM > LDS
