38
F
S1 S4
S2
S3
• Screw S1 moves the video image on the monitor
horizontally.
Screw S2 rotates the image around a point which is
located in the middle of the left side,
and screw S4 rotates the image around a point which
is located in the middle of the right side.
Screw S3 will focus the lens.
• Re-attach the cover after adjusting.
Standard Video Controls
