ARRI M18 - Testing Door Latch Adjustment

M18 – Service Manual Page 10 of 19
Important: Do not try to adjust the SSA with the door latch!
To test the Door Latch adjustment
Use the screw to adjust the door latch if
needed.
.
When you close the lens door completely
there should be a small gap (movement)
between the black lens door and the blue
front housing.
Tip: If the gap is too big then the safety
loop can be opened and the lamphead will
not strike.
