TRINITY 2 balance quick guide 14
Add Batteries
Batteries
► Add two compact 90 watt or maximum 150 watt
batteries to either battery mount.
► Double check that all cables are properly connected.
Docking Bracket Balance Position
Balance Rod
► Move the Balance Rod clamp into a 45° position.
► Push the rod to the shown position.
Balance Pin
► Lift the Gimbal handle onto the Balance Pin.
