Chapter 2: Set up your SURFboard mAX home network
Fiber-based Modem or Gateway Internet access is proided through a single
device. The optical fiber cable connects
to the gateway and Wi-Fi is provided
through the built-in functionality of the fiber
gateway device.
I Don't Know My Configuration Your configuration is not covered by one of
the above selections or you are unsure if it
does.
Use the recommendations provided by the app based on your network configuration to
choose the best place in your home for your mAX router.
3. Unpack the mAX unit(s) and accessories. Included are:
■
SURFboard mAX unit(s)
■
An Ethernet cable
■
A power cord
Note: If you have the W121, your two mAX units are interchangeable for router
and satellite. They are assigned the roles of router or satellite upon configuration.
4. Tap NEXT.
5. Unplug your existing modem from power and tap NEXT.
6. Connect a mAX unit to your modem with the Ethernet cable. Be sure to use the yellow
WAN port on the underside of the mAX. Tap NEXT.
7. Connect your modem to power with your modem's power cable. Tap NEXT.
8. Connect your mAX unit to power via the provided power cord. Wait for the LED on the
mAX unit to alternate white and blue before you tap NEXT.
Note: If you get a message that Wi-Fi is disabled, follow the directions on the
screen to enable Wi-Fi before continuing.
SURFboard mAX User Guide Standard Revision x.1 16
