Chapter 1: Get started
LED behavior
This table describes the mAX LED behavior.
LED Behavior Action
Solid amber Booting
Solid white Boot successful
Rapidly
alternating green
and white
(~1 sec
increments)
Attempting to pair with mobile app via Wi-Fi during on-boarding
Slowly alternating
green and white
(3 sec increments)
Paired with mobile app via Wi-Fi during on-boarding
Slowly alternating
blue and red
(3 sec increments)
Paired with mobile app via Wi-Fi during on-boarding and WAN down
Solid blue
"Normal" state; on-boarding complete; connected to Internet; latest
firmware installed.
Rapidly
alternating blue
and amber
(~1 sec
increments)
Downloading software in background
Solid blue mAX good WAN connection state
Solid red mAX disconnected WAN connection state
SURFboard mAX User Guide Standard Revision x.1 8
