26 of 36
EN
NOTE: when you insert the brazier support,
be sure you install it on the stopping device
on the support brackets (Pict. 10). The brazier
flap for pellets fall (Pict. 11) must be addressed
to the inner part of the combustion chamber.
Pict. 11: how to insert the brazier
Pict. 10: how to insert the brazier support
Pict. 13: activated scraper
Daily cleaning with a scraper
When the pellet insert is switched off and cold, start
up the scrapers of the pipe for heat exchange 5-6
times. You need to pull and push the two control
levers set between the front grids through which
the air ows outdoor. Use the provided dedicated
tool (detail 1, pict. 12) to activate the scraper: as-
semble the hook at the one end of the detail 1 in
the hole on the scraper and pull the scraper several
times.
• Push the scrapers toward the pellet insert with
the door closed (Pict. 13).
• Pull the scrapers toward themselves with the door
closed (Pict. 13).
Pict. 12 dedicated tool to activate the scraper
1
